SteadyIMAGE

Specifications


	MAIN FEATURES

	Power Failure Safe:

		All user settings stored in EEPROM

	Application Setup:

		12 DIP-switches for parameter selection

		6-key keypad for control of OSD.

	Board Features:

		Equator 300 MHz BSP-15 DSP

		Real Time Clock with battery backup

		Video decoder, ITU 656 YUV 4:2:2 format

		Video encoder, ITU 656 YUV 4:2:2 format

	Stabilization Correction:

		X/Y correction

		Rotation correction

		Zoom correction

	Shake Capture Range Presets:

		Small/medium/large

	Minimum Output Video Latency:

		approx. 100 milliseconds

	Exclusion Areas:

		Default Region of Interest is entire Frame

	Frame:

		Definition of top and bottom frame exclusion areas (exclude lettering)

	Demo Mode:

		Picture-in-picture demo mode

Videos from Security cameras often shake. Shake comes from many sources and is amplified by high-power zoom lenses. Swaying buildings, wind-driven locations, cameras mounted near machinery , PTZ servos and of course all mobile applications – they all generate unsteady videos. A steady video and sharp details are a requirement for good and high quality security video.


Video input:	• 1 composite or S-video • Auto-detect PAL or NTSC	Operating Conditions:	•Temperature: 0 – 50°C • Humidity: 20 – 95%, non-condensing
Video Output:	• 1 composite or S-video	Dimensions and Mechanics:	• Height: 1.5” (4 cm) • Width: 6.7” (16.9 cm) • Length: 7.3” (18.5 cm) • Weight: 1.1 kg • Finish: Black anodized aluminum
Power:	• External power supply • 12VDC, 1.2A
