Compliance:
|
ISO/IEC
13818-3,2(MPEG-2) |
|
Power
Consumption:
|
2.5A@+12V
|
| Stream
Types: |
Transport,
Half PEL accuracy |
Dimensions: |
7.5"
x 10" x 3.5"
(19 x 25.4 x 9)cm |
| Video
Bit Rate: |
VBR,
1-12 MBs |
Weight: |
5lb/2.5kg |
|
|
|
|
|
|
| |
|
|
Horizontal
Resolution:
|
720,
640, 544, 480, 360, 320, 160
|
|
Motion
Estimation:
|
Pand
B-pictures ±100(H) x ±34(V)
|
Vertical
Resolution:
|
480,
240, 112 (NTSC)
576, 288, 144 (PAL)
|
Preprocessor:
|
Programmable
2D (7X6) filter spatial noise reduction
|
| INPUTS |
| Composite
Video |
|
Audio |
1
x Input Impedance:
|
75
Ohm,
1.0V p-p |
1
x Balanced Level:
|
Up
to 3V p-p |
Standards:
|
525/60(NTSC),
625/50(PAL)
|
Load:
|
Single-ended
high impedance |
| OUTPUTS |
| Composite
Video |
|
Audio |
3
x Output Impedance:
|
75 Ohm,
1.0V p-p |
1
x Balanced Level:
|
Up to
3V p-p |
Standards:
|
525/60(NTSC), 625/50(PAL)
|
Load:
|
Single-ended high
impedance |
*
All Specifications, Modifications and product
availability are subject to change without notice.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
